Categories

Miscellaneous Part List

Image Description Price
AG1-EK
AG1 Series Emergency Kit
N/A
AG2-EK
AG2 Series Emergency Kit
N/A
DB-201NF
16" PC 4" to 3" Swedge - No Flange
$104.00
DB-219
Pressure Tube Bracket - Fan Mount
$2.50
RVA2-EK
RVA2 Series Emergency Kit
N/A
TP-1
Control Box Top Cover - Blue Stock
$17.75
TP-2
End Panel With No Holes
$8.50
TP-3
End Panel with Mark17DX Circuit Board Holes
$8.75
Placeholder TP-4
Blue Stock Steel Shell
$45.00
TP-7
1/4-20 X 1/2" Machine Screw
$0.12
TP-7A
1/4-20 Hex Nut
$0.12
TP-10
Metal Conduit 4" x 1/2"
$1.35
TP-11
Glo-Bar Igniter Box
$10.00
TP-12
Glo-Bar Igniter Box Cover
$7.75
TP-14
Sight Glass Gasket
$3.00
TP-15
Sight Glass
$5.15
TP-16
Sight Glass Washer
$0.91
TP-17
Sight Glass Kit
$9.00
Placeholder TP-18
1/4" x 20" X 3/8" - Self Tap Bolt
$0.14
TP-30
Eye Bolt
$1.25
TP-31B
V2. Control Box Bracket
$1.14
TP-33A
1/2" X Close Nipple
$1.75
TP-34
3/8" X 1/2" Bushing
$2.50
TP-35A
Pipe Nipple 1/2" X 4"
$3.30
TP-47
Spacer
$0.90
TP-52
6 X 3/4" Sheet Metal Screw
$0.20
TP-53
Exhaust Box Divider
$8.75
TP-54A
Burner Box Divider
$8.75
TP-56C
Universal Vinyl Atmospheric 1/4" Vinyl Tube
$2.75
TP-57A
DTH/S "Curly Que" Aluminum Extension Pick-up Tube
N/A
TP-57D
1/4" Plastic Back Washer for TP-57C
$0.41
TP-59
Hex Nut / Lock Washer
$0.10
TP-62
#8 X 1/2" Aluminized, Slotted Sheet Metal Screw
$0.07
TP-63
90° Exhaust 1/4" Aluminum Atmospheric Tube
$2.75
TP-63A
90° Exhaust 1/4" Aluminum Atmospheric Tube
$2.75
TP-66
2" X 4" Outlet Box
$5.65
TP-67
2"X 4" Outlet Box Cover
$1.30
TP-68A
Strain Relief Bushing
$1.05
TP-68B
Large Strain Relief Bushing
$4.40
TP-69
Brass Compression Fitting
$3.40
TP-70
Control Box Cover Gasket
$1.90
TP-71
Radiant Sensor Mica
$5.50
TP-72A
Door Switch. Discontinued. Replace with TP-CPA-2.
$9.00
TP-75
Washer With Shoulder
$0.75
TP-76
Rubber Grommet
$1.85
TP-80
6-32 X 1" Machine Screw
$0.15
TP-81
#6-32 Hex Nut
$0.12
TP-84
1/2" Female / Male Flare Fitting
$10.00
TP-85
1/2" Male / Male End Fitting
$10.00
TP-97
1/4" X 1/4" Brass Internal / External Atmospheric Barb Fitting
$4.00
TP-100
3/8" Adapter Fitting
$6.80
TP-101
1/2" Adapter Fitting
$7.50
TP-102
9/16" Nut
$1.40
TP-120
Bushing
$0.30
TP-121
Screen
$0.50
TP-123
Tap Plug
$0.29
TP-124
5/8" Plug
$0.47
TP-125
8-3/4" Screw
$0.15
TP-126
Lock Washer
$0.32
TP-205
Glo-Bar Holder
$9.75
TP-206
Glo-Bar Holder Spring Clip
$1.00
TP-208
"Z" Mouting Bracket
$3.25
TP-212
1/2" X 3" Pipe Nipple
$4.00
TP-219
BPS Differential Vinyl Sensing Tube
$4.55
TP-221
Glo-Bar Holder Gasket
$2.75
TP-223
Gas Manifold
$20.00
TP-230A
Fan Wheel - Non -2 Series
$33.00
TP-230B
"Squirrel Cage" Fan Wheel For TP-55A
$31.00
TP-230C
Stainless Steel "Squirrel Cage" Fan Wheel for TP-55A
$44.50
TP-249
3/16" O.D. Atmospheric Plastic Tee
$3.50
TP-321
Ignition Plate Gasket
$1.50
TP-330
Divider Grommet
$1.70
TP-331
Green Self Tap Ground Screw
$0.30
Placeholder TP-337
Electrical Plastic Bushing
$0.13
TP-383
Glo-Bar Igniter Plate
$7.25
TP-553
Igniter Mounting Bracket
$2.75
TP-554
Spark Igniter Gasket
$2.70
TP-583
Direct Spark Igniter Plate
$7.00
TP-832
Thermostat Terminal Strip
$5.00
TP-965
See TP-218
N/A
TP-1232
SV 24V Terminal Plug (2 Prong)
$4.75
TP-1254
Igniter Gasket
$5.25
TP-1283
Mini Igniter Plate
$7.00
TP-1565
Empty 8" x 8" Electrical Box
$61.00
TP-3001
Series 3 Divider Panel
$8.25
Placeholder TP-3002
Series 3 - Left End Exterior Panel - Stainless Steel
N/A
TP-3002A
Series 3 - Control Compartment End Panel - Moulded Plastic
$42.50
Placeholder TP-3003
Series 3 - Right End Exterior Panel - Stainless Steel
N/A
TP-3003A
Series 3 - Fan Compartment End Panel - Moulded Plastic
$42.50
TP-3004
Series 3 - Main Control Box Chassis
$54.00
Placeholder TP-3005
Series 3 - Control Box Chamber Lid - Stainless Steel
N/A
TP-3005A
Series 3 - Valve Compartment Top Lid - Moulded Plastic
$36.00
TP-3010
Series 3 - Service Panel Hinge
$4.15
TP-3011
Series 3 - Spark Ignition Box
$12.75
TP-3012
Ignition Box Cover [Series 3]
$10.75
TP-3033B
Power Entry Plate "B"
$5.50
TP-3033C
Power Entry Plate "C"
$5.50
TP-3033D
Power Entry Plate "D"
$5.50
TP-3033E
Power Entry Plate "E"
$5.50
TP-3044
Gas Manifold
$22.00
TP-3083
Direct Spark Ignitor Plate
N/A
TP-3094
#8-32 Black Nylon Knurled Head Shoulder Screw.
$1.60
TP-3094A
#8-32 X 1/2" Zinc Coated Steel Knurled Thumb Screw
$3.45
TP-3098
Series 3 - Valve Compartment Side Panel
$8.50
TP-3099
Series 3 - Controls Mounting Panel
$8.50
TP-3099A
Controls Mounting Panel
N/A
TP-3223
Anti-Kink Coil (Qty. 2)
N/A
TP-3224
Thermostat Terminal Strip, 4 Circuit (C)
$12.00
TP-3225
Thermostat Terminal Strip, 5 Circuit (B)
$12.00
TP-3228
Thermostat Terminal Strip, 8 Circuit (A)
$12.00
TP-3260
4 1/2" Pneumatic Tube (Qty. 3)
N/A
TP-6001
Control Mounting Panel
$7.75
TP-6002A
Burner Box Left Side Panel
$15.50
TP-6003
Burner Box Right Side Panel
$15.50
TP-6004
Burner Box Front Panel w/ 9 Weld Studs
$31.00
TP-6005
Burner Box Top Cover
$22.50
TP-6006
Burner Box Bottom Panel
$10.00
TP-6007
Burner Box Rear Panel, Upper
$15.00
TP-6009
Burner Center Panel
$21.75
TP-6012
Burner and Ignition Supporting Frame
$13.75
TP-6013
Service Access Handle
$7.50
TP-6019
Exhauster Collector Box
$29.50
TP-6020A
Fan Restrictor Plate - 40
$8.25
TP-6020B
Fan Restrictor Plate - 60
$8.25
TP-6020C
Fan Restrictor Plate - 80
$8.25
TP-6021A
Fan Gasket
$4.25
TP-6021B
Tube Flange Gasket
$4.25
TP-6021C
Inducer Box Insulation
N/A
TP-6022
5/16" - 18 Keps Nut
$0.59
TP-6023
Rubber Grommet (Black)
$1.88
TP-6024
Gas Inlet Adapter
$9.25
TP-6025
Dual Pole, Dual Throw Switch
$12.00
TP-6027
1/2 inch Plastic Plug
$0.60
TP-6044
Manifold Pipe with Foot Mounts
$36.50
TP-6047
5" x 1/2" Gas Inlet Pipe
$6.00
TP-6048
1/2" Gas Inlet Street Elbow
$10.50
TP-6053
Ignitor & Sense Mounting Plate
$3.85
TP-6065
17.5" x 5/32" I.D. Silicone Pressure Tubing
$4.50
TP-6069
Port Barb Fitting
$4.25
TP-6074
Sight Glass Plug
$4.00
Placeholder TP-6078
Reflector Supports
N/A
TP-6084A
U-End Reflector End Cap
$18.00
Placeholder TP-6085
Reflector Angle Limitation Bracket
N/A
TP-6085A
Burner Reflector End Cap
$18.00
Placeholder TP-6087B
Reflector Stop
N/A
Placeholder TP-6089
Reflector End Assembly w/ Saddle Brackets & Stops
$56.00
TP-6089A
Reflector End Assembly w/ Saddle Brackets & Stops
$56.00
TP-6201
Post Purge Component Plate
$7.25
V-10
Regulator Vent Line
$15.25
V-12
Baffle Plate
$8.00
V-23
16" Isolation Boot
$110.00
V-24
Worm Gear Clamp
$7.50
V-25
1/8" Vacuum Plug Tap
$1.15
V-51
Glo-Bar Connector
$5.60
V-55A
4" Adapter
$48.00
V-56A
5" Adapter
$66.00
V-57A
6" Adapter
$68.00
V-63
DRV Vinyl Pick-up Atmospheric Tee Fitting 1.5" X 1.5" X 6.5"
$5.25
V-107
90° 1/2" NTP Elbow
$9.50
V-108
Elbow Attachment Fitting 3 Piece Union
$19.00
